Submersible Pump Test Rig

Submersible pump Test Rig is a self-contained unit operated on closed circuit basis containing a sump tank. The set-up consists of a submersible pump coupled with a DC Motor. Power input to the DC Motor is varied by means of a Thruster controlled DC Drive to vary the RPM of motor. A RPM Indicator with Proximity sensor indicates the RPM of Pump. Flow of water is measured by using measuring tank and stopwatch. Vacuum gauge is fitted on suction line and Pressure gauge is fitted on delivery line to measure the pressure.

The experimental unit includes a self-priming Submersible pump, a ball valve on the outlet side and manometers on the inlet and outlet side. An asynchronous motor drives it. The speed is infinitely adjustable by using a frequency converter. A ball valve is used to adjust the head.

The experimental unit is positioned easily and securely on the work surface of the pump draws in water from the tank on the flow rate is determined volumetrically by flowing back into the measuring tank.
